Rocky Mountain Altitude A50
Details
From commanding the clock to holding your own on weekend rides. The Altitude Alloy is purpose-built to go fast and demolish steep trails. Its total enduro capabilities can help you secure that “top step” and tackle demanding group rides with confidence. The Altitude Alloy features internal routing, size-specific tune, and the refined RIDE-4™ adjustment system. With so much capability in your corner, it’s time to push limits, climb faster, and charge.
OVERVIEW
Wheel Size : 29"
Intended Use : Enduro
Rear Travel : 160
Specs
| Frame | FORM™ Alloy | Full Sealed Cartridge Bearings | BSA Bottom Bracket | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 160mm Travel. FORM™ Alloy Rear Triangle |
|---|---|
| Fork | Fox 38 Float EVOL GRIP Performance Series 170mm | 27.5 = 37mm Offset | 29 = 44mm Offset |
| Headset | FSA ZS56|66 Reach Adjust| 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
| Rear Shock | Fox Float X Performance | Sealed Bearing Eyelet | 40x10mm F Hardware | SM = 210x55mm | MD - LG - XL = 230x60mm | Size-Specific tune in FAQ |
| Rims/Wheels | WTB ST i30 TCS 2.0 Tubeless | 32H / Tubeless Ready - Tape / Valves Incl |
| Hubs | Front : Rocky Mountain SL Sealed Boost 15mm / Rear : Shimano XT Boost 148mm |
| Spokes | DT Swiss Competition 2.0/1.8/2.0 |
| Tires | F: Maxxis Assegai 2.5 WT 3C MaxxGrip EXO+ Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready |
| Bottom Bracket | Shimano Threaded BBMT501-B |
| Chain | Shimano M6100 |
| Rear Derailleur | Shimano XT |
| Shifters | Shimano SLX |
| Handlebars | Rocky Mountain AM | 780mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp |
| Tape/Grips | ODI Elite Pro Lock On |
| Stem | Rocky Mountain 35 AM | 5° Rise | All Sizes = 40mm |
| Brakes | Shimano SLX Trail 4 Piston | Metal Pads |
| Saddle | WTB Volt Race 142 |
| Seat Post | X Fusion Manic Alloy 30.9mm | Shimano MT500 Remote | SM = 150mm | MD = 170mm | LG - XL = 200mm |
| Weight | 38.082|17.31 KGS |
| Front Travel | 170 |
| Rear Travel | 160 |
| Cranks & Chainring | Race Face Aeffect Cinch | 32T | 24mm Spindle | SM = 165mm | MD - XL = 170mm |
| Cassette | Shimano Deore 10-51T 12spd |
* Subject to change without notice.
